CMA3 OMRON G8L General Purpose Relay SPDT 40A 28*28*26mm Without Shoulder

China Ningbo Anyo Import & Export Co., Ltd. certification
China Ningbo Anyo Import & Export Co., Ltd. certification
Time is flying away, remember the first time we met in Ningbo in the year of 2005. I'm so happy with you and your team. Thanks for your support and let's look forward to the next years together.

—— Mr. Halit vergili

From partner to friend, you always give me surprise for your goods and service. We appreciate it so much. By the way, the pickled fish sauce is so nice. I'm self-confident of my cooking skills again. Don't forgot hot pot date next time.

—— Ms. Nathalie Kruse

I'm Online Chat Now

CMA3 OMRON G8L General Purpose Relay SPDT 40A 28*28*26mm Without Shoulder

CMA3 OMRON G8L General Purpose Relay SPDT 40A 28*28*26mm Without Shoulder
CMA3 OMRON G8L General Purpose Relay SPDT 40A 28*28*26mm Without Shoulder CMA3 OMRON G8L General Purpose Relay SPDT 40A 28*28*26mm Without Shoulder CMA3 OMRON G8L General Purpose Relay SPDT 40A 28*28*26mm Without Shoulder CMA3 OMRON G8L General Purpose Relay SPDT 40A 28*28*26mm Without Shoulder

Large Image :  CMA3 OMRON G8L General Purpose Relay SPDT 40A 28*28*26mm Without Shoulder

Product Details:

Place of Origin: CHINA
Brand Name: ANYO
Model Number: CMA3

Payment & Shipping Terms:

Minimum Order Quantity: 1000pcs
Price: Negotiation
Packaging Details: 2000pcs/carton, 6.9kg, 39.5*31*13.5cm
Delivery Time: 8-10 work days
Payment Terms: L/C, T/T
Supply Ability: 30000PCS per day
Detailed Product Description
Other Name: PCB Power Relay Contact Ratings: 40A 14VDC
Max.switching Voltage: 30VDC Max.switching Current: 40A
Max.switching Power: 560W Initial Contact Resistance: 100mΩMax At 6VDC 1A
High Light:

electromagnetic power relay

,

miniature signal relay

Automotive relay CMA3 (OMRON G8L) SPDT 40A, 28*28*26mm without shoulder



Description:

A relay is an electromagnetic switch operated by a relatively small electric current that can turn on or off a much larger electric current. The heart of a relay is an electromagnet (a coil of wire that becomes a temporary magnet when electricity flows through it). You can think of a relay as a kind of electric lever: switch it on with a tiny current and it switches on ("leverages") another appliance using a much bigger current. Why is that useful? As the name suggests, many sensors are incredibly sensitive pieces of electronic equipment and produce only small electric currents. But often we need them to drive bigger pieces of apparatus that use bigger currents. Relays bridge the gap, making it possible for small currents to activate larger ones. That means relays can work either as switches (turning things on and off) or as amplifiers (converting small currents into larger ones).



Advantages:

you can control the switch automatically by sending a small signal to the electromagnet so this signal switches on the circuit of a big appliance like a water pump motor, washing machine, elevator motor….anything. Electronic controllers uses very low current and voltage, so in order (for example) to switch on your big desk lamp or room lamp or washing with your computer in a smart home system…you make a controller circuit to which takes the control signal.



Applications:

Suitable for automobile, machine, electronic equipment, air conditioner and household appliances applications. PC board mounting and direct insert mounting available.
